1 Phase Sentri Servo Controlled Voltage Stabilizers

Frequent fluctuations or variation of power not only causes financial loss but man power loss too! Sentri Servo Controlled Voltage Stabilizers beats these happenings and provides all extra care needed to your valuable equipments.

View Details

sentri2
sentri3
sentri1

Specifications:



  • INPUT VOLTAGE RANGE: AS SPECIFIED (Eg. 170V-270 V).

  • INPUT SUPPLY FREQUENCY: 45Hz-55Hz.

  • OUTPUT VOLTAGE: AS SPECIFIED (Eg. 230V/240V ±1%)

  • VOLTAGE REGULATION: ±1%

  • RATE OF CORRECTION: USUALLY 25V/ SEC/PHASE BUT DEPENDS ON RATING BETTER THAN 97%

  • EFFICIENCY::BETTER THAN 97%

  • WAVEFORM DISTORTION: NILL

  • EFFECT OF LOAD POWER FACTOR: NIL

  • AMBIENT TEMPRETURE: : 0- 50°C Max.

  • TYPE: 1 PHASE



FEATURES:

  • OUTPUT VOLTAGE SENSING FOR VOLTAGE CORRECTION & FOR U/V & 0/V TRIP
  • OVERVOLTAGE & UNDERVOLTAGE TRIP BY MEANS OF CONTACTOR / RELAY'S
  • VOLTMETER WITH SELECTOR SWITCH TO SEE INPUT & OUTPUT VOLTAGES
  • SHORT CIRCUIT & OVERLOAD PROTECTION BY MEANS OF MCB / FUSE/MCCB
  • ADJUSTMENT: OUTPUT VOLTAGES ADJUSTMENT OF + 5V/PHASE WILL BE PROVIDED BY MEANS OF POTENTIO METER ON FRONT PLATE
  • CONTROLS: AUTO/MANUAL INCASE OF AUTO MODE FAILURE YOU CAN SET OUTPUT VOLTAGE THROUGH MANUAL MODE.



OPTIONAL FEATURES::

  • BY PASS FACILITIES
  • RFI FILTER & SPIKE SUPPRESSOR
  • GENERATOR COMPATIBLE CIRCUIT
  • TIME DELAY CIRCUIT : OUTPUT POWER ON WITH SPECIFIED TIME DELAY —N ISOLATION TRANSFORMER /ULTRA ISOLATION TRANSFORMER AT OUTPUT
  • AMMETER: TO SEE LOAD CURRENT'S
  • DIGITAL VOLTMETER & DIGITAL AMMETER.







stabilizers1

3 Phase Sentri Servo Controlled Voltage Stabilizers

Frequent fluctuations or variation of power not only causes financial loss but man power loss too! Sentri Servo Controlled Voltage Stabilizers beats these happenings and provides all extra care needed to your valuable equipments.

View Details

stabilizers1
stabilizers2
stabilizers3

Specifications:



  • INPUT VOLTAGE RANGE: AS SPECIFIED (Eg. 300V TO 470 V ;4 WIRE,50Hz,UNBALANCE) .

  • INPUT SUPPLY FREQUENCY: 45Hz TO 55Hz.

  • OUTPUT VOLTAGE: AS SPECIFIED (Eg. 400V/ 415 V ±1%, 4 WIRE, 50 Hz,BALANCE)

  • VOLTAGE REGULATION: ±1%

  • RATE OF CORRECTION: : USUALLY 25V/ SEC/ PHASE BUT DEPENDS ON RATING.

  • EFFICIENCY::BETTER THAN 97%

  • WAVEFORM DISTORTION: NILL

  • EFFECT OF LOAD POWER FACTOR: NIL

  • AMBIENT TEMPRETURE: : 0- 50°C Max.

  • TYPE: 3 PHASE



FEATURES:

  • OUTPUT VOLTAGE SENSING FOR VOLTAGE CORRECTION & FOR U/V & 0/V TRIP
  • - OVERVOLTAGE & UNDERVOLTAGE TRIP BY MEANS OF CONTACTOR/RELAY'S
  • VOLTMETER WITH SELECTOR SWITCH TO SEE INPUT & OUTPUT VOLTAGES
  • SHORT CIRCUIT & OVERLOAD PROTECTION BY MEANS OF MCB / MCCB/SFU
  • ADJUSTMENT: OUTPUT VOLTAGES ADJUSTMENT OF ± 5V PER PHASE WILL BEPROVIDED BY MEANS OF POTENTIO METER ON FRONT PLATE
  • CONTROLS: AUTO/ MANUAL INCASE OF AUTO MODE FAILURE YOU CAN SET OUTPUT VOLTAGE THROUGH MANUAL MODE.
  • BUILT IN SINGLE PHASE PREVENTER



OPTIONAL FEATURES::

  • BY PASS FACILITIES
  • RFI FILTER & SPIKE SUPPRESSOR
  • GENERATOR COMPATIBLE CIRCUIT
  • TIME DELAY CIRCUIT : OUTPUT POWER ON WITH SPECIFIED TIME DELAY —N ISOLATION TRANSFORMER /ULTRA ISOLATION TRANSFORMER AT OUTPUT
  • AMMETER: TO SEE LOAD CURRENT'S
  • DIGITAL VOLTMETER & DIGITAL AMMETER.
